Error detection and correction using parity bit computation
A parity bitor check bitis a bit added to a string of binary code to ensure that the total number of 1-bits in the string is even or odd. Parity bits are used as the simplest form of error detecting code. In the case of even parity, for a given set of bits, the occurrences of bits whose value is error detection and correction using parity bit computation is counted. If that count is odd, the parity bit value is set to 1, making the total count of occurrences of 1s in the whole set including the parity bit an even number.
If the count of 1s in a given set of bits is already even, the parity bit's value is 0. In the case of odd parity, the coding is reversed.
For a given set of bits, if the count of bits with a value of 1 is even, the parity bit value is set to 1 making the total count of 1s in the whole set including the parity bit an odd number. If the count of bits with a value of 1 is odd, the count is already odd so the parity bit's value is 0.
If a bit is present at a point otherwise dedicated to a parity bit, but is not used for parity, it may be referred to as a mark parity bit if the parity bit is always 1, or a space parity bit if the bit is always 0. In such cases where the value of the bit is constant, error detection and correction using parity bit computation may be called a stick parity bit even though its function has nothing to do with parity. Parity bits are generally applied to the smallest units of a communication protocol, typically 8-bit octets bytesalthough they can also be applied separately to an entire message string of bits.
In mathematics, parity refers to the evenness or oddness of an integer, which for a binary number is determined only by the least error detection and correction using parity bit computation bit.
Error detection and correction using parity bit computation telecommunications and computing, parity refers to the evenness or oddness of the number of bits with value one within a given set of bits, and is thus determined by the value of all the bits. It can be calculated via a XOR sum of the bits, yielding 0 for even parity and 1 for odd parity.
This property of being dependent upon all the bits and changing value if any one bit changes allows for its use in error detection schemes. If an odd number of bits including the parity bit are transmitted incorrectly, the parity bit will be incorrect, thus indicating that a parity error occurred in the error detection and correction using parity bit computation.
The parity bit is only suitable for detecting errors; it cannot correct any errors, as there is no way to determine which particular bit is corrupted. The data must be discarded entirely, and re-transmitted from scratch.
On a noisy transmission medium, successful transmission can therefore take a long time, or even never occur. However, parity has the error detection and correction using parity bit computation that it uses only a single bit and requires only a number of XOR gates to generate. See Hamming code for an example of an error-correcting code. Parity bit checking is used occasionally for transmitting ASCII characters, which have 7 bits, leaving the 8th bit as a parity bit.
For example, the parity bit can be computed as follows, assuming we are sending simple 4-bit values This mechanism enables the detection of single bit errors, because if one bit gets flipped due to line noise, there will be an incorrect number of ones in the received data.
In the two examples above, B's calculated parity value matches the parity bit in its received value, indicating there are no single bit errors. Consider the following example with a transmission error in the second bit using XOR:.
There is a limitation to parity schemes. A parity bit is only guaranteed to detect an odd number of bit errors. If an even number of bits have errors, the parity bit records the correct number of ones, even though the data is corrupt.
See also error detection and correction. Consider the same example as before with an even number of corrupted bits:. Because of its simplicity, parity is used in many hardware applications where an operation can be repeated in case of difficulty, or where simply detecting the error is helpful. For example, the Error detection and correction using parity bit computation and PCI buses use parity to detect transmission errors, and many microprocessor instruction caches include parity protection.
Because the I-cache data is just a copy of main memoryit can be disregarded and re-fetched if it is found to be corrupted. In serial data transmissiona common format is 7 data bits, an even parity bit, and one or error detection and correction using parity bit computation stop bits. Other formats are possible; 8 bits of data plus a parity bit can convey all 8-bit byte values. In serial communication contexts, parity is usually generated and checked by interface hardware e.
Recovery from the error is usually done by retransmitting the data, the details of which are usually handled by software e. When the total number of transmitted bits, including the parity bit, is even, odd parity has the advantage that the all-zeros and all-ones patterns are both detected as errors.
If the total number of bits is odd, only one of the patterns is detected as an error, and the choice can be made based on which is expected to be the more common error. Parity data is used by some RAID redundant array of independent disks levels to achieve redundancy. If a drive in the array fails, remaining data on the other drives can be combined with the parity data using the Boolean XOR function to reconstruct the missing data. For example, suppose two drives in a three-drive RAID 5 array contained the following data:.
Should any of the three drives fail, the contents of the failed drive can be reconstructed on a replacement drive by subjecting the data from the remaining drives to the same XOR operation. If Drive 2 were to fail, its data could be rebuilt using the XOR results of the contents of the two remaining drives, Drive 1 and Drive The result of that XOR calculation yields Drive error detection and correction using parity bit computation contents.
This same XOR concept applies similarly to larger arrays, using any number of disks. In the case of a RAID 3 array of 12 drives, 11 drives participate in the XOR calculation shown above and yield a value that is then stored on the dedicated parity drive. A "parity track" was present on the first magnetic tape data storage in Parity in this form, applied across multiple parallel signals, is known as a transverse redundancy check.
This can be combined with parity computed over multiple bits sent on a single signal, a longitudinal redundancy check. In a parallel bus, there is one longitudinal redundancy check bit per parallel signal. Parity was also used on at least some paper-tape punched tape data entry systems which preceded magnetic tape systems.
The 8th position had a hole punched in it depending on the number of error detection and correction using parity bit computation holes punched.
